Industrial communication gateway is a device with protocol conversion, data processing and remote control functions. By realizing interconnection between different devices and systems, it enables various data and instructions to be freely transmitted between different protocols. Its core function is protocol conversion, that is, translation and adaptation between different communication protocols to ensure that data can be correctly parsed and transmitted.
The hardware components of industrial communication gateways mainly include processors, memories, communication modules, interfaces and power supplies. Among them, the processor is responsible for data processing and decision-making; the memory is used to store programs and data; the communication module is used to communicate with cloud systems and field devices; the interface is used to connect and communicate with various types of equipment; and the power supply provides power supply. The software components include operating systems, data processing and analysis software, communication protocol stacks and application software.
Industrial communication gateways are widely used in various fields, especially playing an important role in intelligent manufacturing, energy management, smart cities and other fields. In the field of intelligent manufacturing, the industrial communication gateway can realize the interconnection between production equipment and improve production efficiency and quality; in the field of energy management, it can connect various energy equipment to realize the collection and monitoring of energy data; in the construction of smart cities , industrial communication gateways can connect various devices and sensors in the city, realize the collection and sharing of urban data, and provide better decision-making support for city managers.
| Parameter name | UW2132 technical indicators |
| Operation processing | Embedded 32-bit CPU, 120MHz, 128K RAM, 1MB NANDFLASH |
| Communication interface |
1 channel industry standard 100Mbps Ethernet, RJ45 standard port, Modbus TCP slave protocol, supports 16 TCP Master simultaneous connections 5-way isolated RS485 communication interface; each channel supports 16/32 RTU intelligent communication devices, a total of 80/160 RTU intelligent communication devices; |
| Communication parameters |
Baud rate 2400bps-115.2kbps Verification method: even/odd/no verification Data bits: 7 bits/8 bits; Stop bits: 1 bit/2 bits |
| Communication commands |
Support function codes: 01H, 02H, 03H, 04H, 05H, 06H, OFH, 10H Communication command size: 1024 |
| Register area |
Al input register (Al-3 area): 4096 WORD AO holding register (AO-4 area): 4096 WORD; DI discrete input (Dl-1 area): 8192 BIT; DO holding coil (DO-0 area): 8192 BIT; |
| Configuration Tool | UWinModGate software, a project-based multi-gateway configuration and management method, a single project can configure and manage 256 Modbus communication gateways |
| Anti-interference |
EN61000-4-2(ESD), Level 3a; EN61000-4-4(EFT), Level 3a; EN61000-4-5(Surge), Level 3a; |
| Power supply | 24VDC/24VAC 5W; |
| Ambient temperature | Working temperature: -20℃-70℃; Storage temperature: -40℃-85℃ |
| Dimensions | 120mm×77mm×42mm; Weight: 220g; |
| Other parameters | Extensible to support 2-way redundant UWinCNet communication interface |
